Today a new blog in the Bootstrap CoaXPress features blog series. This time we will take a closer look at the ConnectionConfig and the related ConnectionConfigDefault feature. ConnectionConfig is one of the most used bootstrap features by the system engineer. This feature can be used to set the number of connections you would like to use…
The EMVA1288 is a great standard to start talking about applications instead of about definitions of important high-performance industrial camera parameters. In this blog we want to talk about the definitions in the standard. For our previous discussions on the EMVA1288 standard, please click here. Not everyone uses the EMVA1288 standard to report on camera parameters,…
Bootstrap CoaXPress features blog series CoaXPress is an interface standard. This means that some obligatory features are defined that should be available in each camera and/or frame grabber to make data transfer possible. StreamPacketSizeMax is one of them. For CoaXPress, the features related to the interface between frame grabber and camera are grouped together in…
In our last blog we discussed the origins of latency and jitter in a triggering scheme for a CoaXPress camera. In this blog we will continue by zooming in on the actual magnitude of the latency and jitter. What is the latency and jitter related to the CoaXPress interface? To answer this question let us…
Determining the latency and jitter in an imaging system is a difficult task. Each component in the system can contribute to these parameters. You have to take into account your frame grabber, the interface and the camera. Latency can occur at the start of the imaging process. In that case it is defined as the…
What to consider when interpreting an EMVA1288 report The EMVA1288 standard is a great standard – it assures that everybody speaks the same language. So you avoid having to ask questions like: how do you define your dynamic range, temporal dark noise, or saturation capacity. Or if you forget to ask that question and you…
April 15th to 19th, Adimec will exhibit at the SPIE Defense + Commercial Sensing conference in Orlando (US) in booth #606. We will demonstrate our latest advancements with our TMX CMOS rugged camera series including the Adaptive Resolution and eZoom functionality in 4k UHD color. With the Adaptive Resolution functionality, the TMX series is designed…
Adimec Connect & GrabTM wraps the whole digital imaging implementation process into a quick and easy package that allows quick and easy single or multiple camera integration. Typical time to start evaluating the first images is less than one hour. The connect & grab experience is twofold. Connect One part of the experience is related…
Adimec is introducing a new 50-megapixel camera the S-50A30 based on the CMOSIS CMV50000. The new camera provides more than just higher resolution. This CMOS camera, provides inspection accuracy increases, the highest inspection throughput at 50 Mpx, and the next step in image quality. This is a three-part series that illustrates why to choose a…
According to the CoaXPress standard, triggering over CoaXPress (CXP) has a fixed latency of 3.4 µs with an accuracy of ± 4 ns. In this blog I will show you what these numbers mean to the vision engineer. The CXP standard is a digital video transmission standard. The frame grabber sents the trigger signal as…
