CLA for C-arms used in X-ray medical imaging
Adimec’s next generation of camera lens assemblies for C-arms in X-ray medical imaging

Adimec’s OEM Camera Lens Assembly (CLA) portfolio for medical X-ray imaging consists of the PEARL and RUBY series. Both provide 1k2 30 frames per second (fps) real-time digital imaging in Image Intensifier based equipment. They deliver quality images while reducing cost, strengthening reliability, simplifying installation, and service. Our CLAs cover dose ranges from fluoroscopy through high dose exposures.

X-ray CLA portfolio

  • PEARL offers quality 1k2 CCD imaging with diversity in interfacing, embedded clinical processing and flexibility to fit dose ranges.
  • RUBY targets 1k2 imaging with break-through cost-effectiveness for fluoroscopy mobile C-arms. RUBY is Adimec’s new innovative CLA with CMOS sensor technology and patented “digital iris” concept.

Product Information

Healthcare cameras X-ray CLA portfolio

Product configuration table

Overview of product configuration details between RUBY, PEARL-F and PEARL-E.

FEATURESRUBYPEARL-FPEARL-E
Dose Range [nGy/im](4 .. > TBD) (1)4 .. > 450 (1)4 .. > 9000 (1)
Irisdigital iris
(analog+digital gain)		motorized iris
(digital gain)		motorized iris
(digital gain)
NDF2 set fixed NDF
service adjustable		fixed NDF
(factory optional)		motorized NDF wheel
user selectable
(4 sets predefined)
Dose ControlABC (video) I/OABC (video) I/OABC (video) I/O
AEC (photodiode) I/O
Video InterfaceGigEGigE
optional: CL, LVDS, DVI		GigE
optional: CL, LVDS, DVI
Defect Pixel CorrectionYESYESYES
Clinical Image Processing–YESYES
II-output Compatibility25 mm25 mm
optional: 20 mm		25 mm
optional: 20 mm

NOTE: (1) Factory configurable via NDF

RUBY & PEARL Healthcare cameras

Image processing RUBY

Overview of the image processing functionality supported by RUBY

FEATURESRUBY GigE
Image Correction
Defect pixel correction
ABC & AGC
based on video measurement field (user programmable)
AEC
photodiode measurement - photo timing		Not Available
Clinical Image Processing
Edge enhancement, Noise reduction, Grey invert,
Contrast & brightness enhancement, White compression 		Not Available
Image Orientation
Horizontal & Vertical Flip
Real-time Digital Rotation, Zoom & Pan
at 1k2 30fps		Not Available
Image Overlay
Optical alignment support overlay
Last Image Repeat/HoldNot Available

RUBY CLA

Image processing PEARL

Overview of the Image Processing functionality supported by PEARL.

FEATURESPEARL-F/E GigE/CL/LVDSPEARL-F/E DVI
Image Correction
Defect pixel correction, II-shading correction
ABC & AGC
based on video measurement field
(user programmable)
AEC
photodiode measurement - photo timing
PEARL-E only
PEARL-E only
Clinical Image Processing
Edge enhancement, Noise reduction,
Grey invert,
Contrast & brightness enhancement,
White compression
Image Orientation
Horizontal & Vertical Flip
Real-time Digital Rotation, Zoom & Pan
at 1k2 30fps		OptionOption
Image Overlay
Clean circle overlay, Optical alignment support overlay
Last Image Repeat/Hold
Image Repeat:
allows re-processing with changed settings
Image Repeat:
allows re-processing with changed settings
