S-25A30 camera

S-25A30-CL

High Resolution Metrology Camera

The SAPPHIRE S-25A30 CameraLink camera delivers 25 megapixel images at 32 fps. The combination of Adimec image quality, compact form factor and low power usage makes the camera ideal for inspection systems that require high resolution to increase throughput or accuracy.

  • VITA 25K sensor
  • 5120 x 5120 pixels at 32 fps
  • Flat Field Correction
  • Power dissipation < 7,5 W
  • No forced cooling required
  • Compact design

Yield reliability

Maximum system reliability

icon image sensor

Active sensor alignment

Device-to-device repeatability

Specifications

Sensor
  • VITA25k
  • Optical size: 35 mm
  • Resolution: 5120 (H) x 5120 (V)
  • Pixel size: 4.5 x 4.5 μm
  • Global shutter CMOS
Monochrome / Color choices
  • Monochrome
  • Color
Interface
  • Camera Link (Full and Deca)
Performance
  • Dynamic range: > 52 dB
  • Full well: 13 ke-
Framerate
  • 32 fps
Image acquisition
  • Continuous or controlled
Triggering
  • Internal or external
Functionality highlights
  • Defect pixel correction
  • Flat Field Correction
  • Multi band ROI
Output resolution
  • 8 or 10 bit
Dimensions

S-25A30 outline drawing

Weight
  • Camera excl. lensmount: 400 g
Power
  • Input voltage: 10 – 24 V
  • Power dissipation: < 7.5 W
Operating temperature
  • Ambient temperature: 0°C  to +30°C
Reliability
  • MTBF > 75000 h @ 40°C
Testing

Every camera is 100% tested on all specifications

Accessories
  • F-Mount
  • TFL-II Mount
  • T2 -Mount
  • M42-Mount
