Q-21A230x/CXP-PA

Sensor

• GPIXEL GSPRINT4521
• Optical format: 29.5 mm
• Resolution: 5120 (H) x 4096 (V)
• Pixel size: 4.5 x 4.5 μm
• Sensor bit depth: 12 bit
• Global shutter CMOS

Monochrome / Color choices

• Monochrome
• Color
• Removable cover glass (monochrome)

Interface

• CoaXPress – CXP 3/6/10/12
• 2 and 4 lanes configurable

Framerate

• 228.8 fps

Performance

• Dynamic range: > 68.7 dB
• Full well: 33.6 ke-

Operating modes

• Maximum full well
• High full well
• Maximum dynamic range
• High sensitivity

Functionality highlights

• Defect pixel correction
• Factory calibrated uniformity correction
• Low Frequency Flat Field Correction
• Sensitivity matching
• User data storage

Output resolution

• 8, 10 or 12 bit

Image acquisiton

• Continuous or controlled

Triggering

• Internal or external

Dimensions

Weight

• Camera excl. lensmount: 600 g
• Heatsink: < 75 g
• Heatsink and fan: < 100 g

Power

• Input voltage: 2 x 24 Vdc PoCXP
• Power dissipation: typ. 16 W

Operating temperature

• Sensor temperature: +5°C  to +70°C, or
• Maximum housing temperature: 50°C

Reliability

• MTBF > 75000 h @ 30°C

Compliance

• CE
• ROHS

Testing

• Every camera is 100% tested on all specifications

Accessories

Standard

• No accessories

Optional

• Heatsink
• Heatsink and fan
• Fn-mount
• M42-mount fixed
• Other lensmounts available on request
