SAPPHIRE 50 Mpx CoaXPress camera

S-50A30-Jx/CXP

High Resolution Metrology Camera

 The SAPPHIRE 50 Mpx CoaXPress camera delivers 7920×6004 pixel resolution at over 30 fps with 4.6 micron square pixels. The camera is fully compatible with the S-25 and Q-12 CoaXPress Adimec offers.

  • AMS CMOSIS CMV50000 sensor
  • 7920 x 6004 at 30 fps
  • Dynamic range 64 dB
  • Dark and bright uniformity corrections
  • No forced cooling required
  • Adimec Connect & Grab™

Yield reliability

Maximum system reliability

icon image sensor

Active sensor alignment

Device-to-device repeatability

Specifications

Sensor
Monochrome / Color choices
  • Monochrome
  • Color
Interface
  • CoaXPress – CXP 3/6
  • 1, 2 or 4 lanes configurable
Performance
  • Dynamic range: > 64 dB
  • Full well: 14.5 ke-
Framerate
  • 30+ fps
Image acquisition
  • Continuous or controlled
Triggering
  • Internal or external
Functionality highlights
  • Defect pixel correction
  • Pixel based DSNU correction
  • Low Frequency Flat Field Correction
  • Sensitivity matching
Output resolution
  • 8, 10 or 12 bit
Dimensions

Weight
  • Camera excl. lensmount: 400 g
Power
  • Input voltage: 24 Vdc PoCXP
  • Power dissipation: < 11 W
Operating temperature
  • Ambient temperature: 0°C  to +30°C, or
  • Maximum housing temperature: 50°C
Reliability
  • MTBF > 75000 h @ 50°C
Testing

Every camera is 100% tested on all specifications

Accessories
  • F-Mount
  • TFL-II Mount
  • T2 -Mount
  • M42-Mount
  • M72-Mount*

*Available on request

This camera is not available for new design in’s.  Please contact your sales office for more information.

APPLICATIONS

semiconductor microchip
semiconductor metrology
Solar-cells-500x500
Solar cell inspection
Display Inspection
Flat Panel Inspection
