QUARTZ Q-25A150 with GMAX0505 sensor

Q-25A150x/CXP

High Speed Inspection and Metrology Camera

The QUARTZ Q-25A150 combines the GPixel GMAX0505 sensor with a unique performance in terms of noise, power and easy of integrate. It runs 26 Mpixel at a 150 frames per second at a remarkable power of 11 W.

The Q-25A150 supports all required functionality, such as dark field and (multiple) bright field corrections, in a 65 x 65 x 25 mm form factor. Each camera is calibrated and tested to ensure it meets high quality performance standards as well as exact device-to-device repeatability requirements.

As such this camera is optimized for optical inspection and metrology tools used for semiconductors, PCBAs, displays and many more.

  • Gpixel GMAX0505 sensor
  • 5120 x 5120 pixels at 150 fps
  • Typical 11W power dissipation at full operation
  • Dark and multiple bright field corrections
  • Easy system integration
  • No active cooling required
  • Device-to-device repeatability to support tool matching

Compact outline

Compact outline, fanless design

Image uniformity

icon repeatability

Device-to-device repeatability

Specifications

Sensor
  • GPIXEL GMAX0505
  • Optical format: 18.1 mm
  • Resolution: 5120 (H) x 5120(V)
  • Pixel size: 2.5 x 2.5 μm
  • Global shutter CMOS
Monochrome / Color choices
  • Monochrome
  • Color
  • Removable cover glass (monochrome)*

*Available on request

Interface
  • CoaXPress – CXP 3/6/10/12
  • 1, 2, and 4 lanes configurable
Framerate
  • 150 fps
Performance
  • Full well: 6.8 ke-
  • Dynamic range: > 62.7 dB
Functionality highlights
  • Defect pixel correction
  • Factory calibrated uniformity correction
  • Low Frequency Flat Field Correction
  • Sensitivity matching
  • User data storage
Output resolution
  • 8, 10 or 12 bit
Image acquisiton
  • Continuous or controlled
Triggering
  • Internal CXP trigger
  • External LVDS or galvanically isolated trigger
Dimensions

Q-25A150 outline drawing

Weight
  • Camera excl. lensmount: 195 g
Power
  • Input voltage: 1 x 24 Vdc PoCXP
  • Power dissipation: Typical 11 W
Operating temperature
  • Sensor temperature: +5°C  to +70°C
Reliability
  • MTBF > 75000 h @ 30°C
Compliance
  • CE
  • ROHS
Testing
  • Every camera is 100% tested on all specifications
Accessories

Standard

  • No accessories

Optional

APPLICATIONS

semiconductor microchip
semiconductor metrology
wafer-500x500
Wafer flatness inspection
Wafer inspection
Micro bump inspection
Chip inspection
3D Moire inspection
