特長
CoaXPress information
Advantages
  • 最高130mのケーブル長(フルデータレートの場合は40m)
  • 1本の同軸ケーブルを経由して1.125 Gbit/s から6.25 Gbits/s のデータ転送
  • データーのアップリンク、ダウンリンク、そして電源(ケーブル毎に24V/13W)供給を1本のケーブルで実現可能なソリューション
  • 複数ケーブルによる拡張性
  • 最小の固定レイテンシーでのP-to-P 接続
Adimec ブログ

Read the latest articles »

coaxpress

CoaXPress QUAD Frame grabbers

as-fbd-4xcxp6-2pe8

The QUARTZ Q-12A180 is fully compliant to CoaXPress V 1.0 and 1.1.  To enable 12 Megapixels at 187 fps, The CoaXPress Quad version (4 x CXP-6) is utilized.

CoaXPress CXP-6 Quad (4 x CXP-6) offers a peak transfer rate of 2 GByte/s with data transmission between the camera and frame grabber at up to 25 Gbits/s (4 x 6.25 Gbits/s). The maximum of 9W of power to the camera is also enabled over the one CoaXPress interface cable. This is all with a cable length of up to 68 meters.

We work closely with frame grabber manufactures to ensure seamless integration with our cameras.  Below is a list of available frame grabber models that are compliant with the Q-12A180.  Frame grabber manufacturers are constantly creating new products.  For the latest detailed information and availability of CoaXPress framegrabbers please go to the manufacturers’ website.

Model Description
Firebird FBD-4xCXP6 PCIe 2.0 x8, PoCXP
Model Description
APX-3664 PCIe 2.0 x8, PoCXP
Euresys logo Model Description
COAXLINK Quad PCIe 2.0 x4, PoCXP
Bitflow Model Description
Cyton-CXP4 PCIe 2.0 x8, PoCXP
 Silicon software

Silicon Software

Model Description
microEnable 5 AQ8-CXP6D PCIe 2.0 x8, PoCXP

Matrox

Model Description
Radient eV-CXP PCIe 2.0 x8, PoCXP
